2024 Hustler HyperDrive 60" Van Big Bl EFI Oil Gu&Kw FX1000 EFI

Powerhouse that Delivers Unrivaled Performance.

The HyperDrive® features Hustler’s exclusive HyperDrive transmission system – the largest, most durable drive system in the industry. And, it’s backed by a 3,000 hour drive system warranty.

Features

Hyperdrive Hydro System: A Hustler® Exclusive, Industrial-Grade Pumps And High Torque Wheel Motors, 3-Gallon Reservoir, Oil Cooler And Hot Oil Shuttle.

Hydraulic System Warranty: 3000-Hour Pump And Motor Warranty Unmatched In The Industry.

Large Drive Tire: Large 26" Drive Tires Provide A Smoother Ride Experience.

Vanguard Big Block™ Efi: Optional Vanguard® Big Block™ Efi Engine With Oil Guard. (500 Hour Oil Change)

Vx4® Deck: Fabricated Steel Deck Engineered To Move More Grass At High Speeds While Maintaining Cut-Quality.

Key Specs

Engine Manufacturer: Vanguard Big Block EFI Oil Guard & Kawasaki FX1000, FX1000 EFI

Engine Horsepower: 40, 35, 38.5

Transmission: Danfoss DDC-20 Transmission w/Parker TG wheel motors

Fuel Capacity: Dual fuel tank w/ 12 gallon total capacity

Ground Speed (Fwd): Up to 16 mph

Cutting Width: 60", 60" RD

Cutting Height: 1" to 5.5"

Front Tire: 13 x 6.5-6

Drive Tire: 60": 26 x 14-12, 60" RD: 26 x 12-12

Warranty: 5 Year / 1200 Hour (First 2 Years No Hour Limit)

Engine

Engine Manufacturer: Vanguard Big Block EFI Oil Guard & Kawasaki FX1000 EFI

Engine Horsepower: 35

Displacement: 999cc Kawasaki

Cooling: Air Cooled

Air Cleaner: Canister Style

Engine Warranty: 3 Year Limited

Drive System

Type: Dual Hydrostatic

Transmission: Danfoss DDC-20 Transmission w/Parker TG wheel motors

Hydraulic Lines: Stainless steel Parker Seal-Loc Technology

Reservoir Capacity: 3 gallons

Hydraulic Cooling: Oil Cooler w/9" fan

Fuel Capacity: Dual fuel tank w/ 12 gallon total capacity

Ground Speed (Fwd): Up to 16 mph

Parking Brake: Integrated with steering levers

Deck

Cutting Width: 60", 60" RD

Cutting Height: 1" to 5.5"

Deck Depth: 5.5"

Deck Lift: Foot Operated

Number Of Blades: 3

Blade Length: 20.50"

Blade Tip Speed: 18,600

Spindles: Ductile cast iron with steel shaft and sealed ball bearings

Deck Engagement: Electric PTO Clutch

Deck Material: Fabricated 7 gauge

Spindle Mounts: Reinforced 7 gauge stamped disc

Impact Trim Area: Front of deck: 11 ga. Formed Bump Bar, Side of deck: 1.5" x 375" steel bar

Construction

Frame: 1.5" X 3" steel tubing

Front Axle: Fabricated with tapered roller bearings

Front Caster Wheel: Tapered wheel bearings and debris cap

Front Caster Fork: Fabricated 1/2" steel

General

Seat: I3M Suspension Seat (adjustable armrests & back)

Cup Holder: Yes

Dimensions

Front Tire (Inches): 13 x 6.5-6

Drive Tire (Inches): 60": 26 x 14-12 , 60" RD: 26 x 12-12

Weight (Lbs): 1619-1682, 1727 Rear Discharge

Height (Inches): 47.8, 73.5 w/rops

Length (Inches): 88, 90 Rear Discharge

Width W/ Chute Up (Inches): 66, 64 Rear Discharge

Tire-To-Tire Width (Inches): 57

Productivity (Acres Perhour): 7.76

Warranty

Warranty: 5 Year / 1200 Hour (First 2 Years No Hour Limit)

Dimensions with Catcher

Catcher Style: 3-bag

Powered / Non-Powered: Powered

Catcher Capacity: 12 bushel

Mower Length W/ Catcher: 114.9"

Mower Width W/ Catcher: 70.9"

Style 2: Catcher Style: BAC-VAC

Style 2: Powered / Non-Powered: Powered

Style 2: Catcher Capacity: 10 bushel

Style 2: Mower Length W/Catcher: 108.4"

Style 2: Mower Width W/Catcher: 70.9"
